24W CCT 3000-6000K DMX512 wall washer

CRI		>80
Delivered flux		2160 lm
Delivered efficiency		90 lm/W
Input power		24W
Supply voltage		24V DC
Light colour/CCT		3000K/4000K/6000K/RGB/RGBW
Beam angle		15°/30°/60°/10X60°

Inquire Now

OPTOWW422524V

PARAMETER

IP rating		66
Ik rating		8
Source type		Hight power LED
Source life time		>50,000h at 25°C ambient temperature
CRI		>80
Step McAdam		3
Source flux		2880 lm
Source efficiency		120 lm/W
Delivered flux		2160lm
Delivered efficiency		90 lm/W
Input power		24W
Supply voltage		DC24V
Insulation Class		insulation class III
Power supply		Built in constant current
Material		Aluminum+tempered glass
Light colour/CCT		3000K/4000K/6000K/RGB/RGBW
Beam angle		15°/30°/60°/10X60°
Mounting		surface mount
Reflector color		-
Finishing		Grey

TEMPERATURE LIMITS

Working temperature: -30C° to +50C°

Storage temperature: -50C° to +80C°

LIGHT CONTROL

ON/off/DMX512

CONSTRUCTION

Aluminum lamp body, tempered glass face mask; The lens angle can be selected; The protection level reaches IP66; Surface anodizing or powder electrostatic spraying, the appearance can be customized according to the color of the curtain wall, allowing the product to better integrate into the building.

WARRANTY

• 5-year limited system warranty standard

• Warranty does not cover product failure due to an overvoltage event (power surge)

• For installations where power surge may be possible, NICOR recommends installing additional

surge protection at the electrical distribution panel

SPECIFICATIONS
